Features
SM or MM Available:PC(plane) or APC(8 Degree) Available
Different IL index and various color available
Stable performance index by PIN flexed position of connecting
Standard Fiber arrangement or Customized
Plug Type connector with locking structure
High density which convenant for wiring and management system Comply with Telcordia GR-1435-CORE and RoHS standard
Area of Applications
Telecom Network
System Cabling
Precision telecom equipments
Cable Loopback Inspection
Technical Specification
Item | SM | MM |
Fiber Diameter | 9/125um | 50/125um,62.5/125um |
Insertion Loss(dB) | ≤0.30/≤0.50/≤0.70 | ≤0.50/≤0.70 |
Return Loss(dB) | ≥60 | ≥30 |
Insert - Pull Test | 500 Times ≤0.50dB |
Operating Temperature | -40℃ ~ +80℃ |
Tensile Resistance | 6Kgf |
Ordering Information
MTP Type | EndFace | Fiber Mode | Fiber Count |
Loopback | MTP/PC,APC TO MTP/PC,APC | OS2,OM1~OM4 | 4,8,12,16,24,48core |
