Features
Excellent mechanical endurance
Small form connector-half size of standard connector
Simplex and duplex assemblies available in standard and customized connector
APC Polish
Comply with Telcordia GR-326-CORE specification and RoHS standard
Technical Specification
Item | SM |
Fiber Diameter | 9/125um |
Insertion Loss(dB) | APC≤0.20dB |
Return Loss(dB) | APC≥60dB |
Insert - Pull Test | (1000 times)≤0.3dB |
Interchange | ≤0.2dB |
Operating Temperature | -40℃ ~ +80℃ |
Tensile Resistance | 6Kgf |
Ordering Information
Type | EndFace | Connector Type | Cable Length | Fiber Core | Cable Diameter |
APC patch cord | APC | SC/LC/FC/ST/MU | 1m/2m/3m… | Simplex/Duplex | 0.9/2.0/3.0mm |
