Features
Uniboot with a single Housing
Unique Push-Pull Design and Function
Easy to Assemble and Use
Low Insertion Loss and Back Reflection
High Repeatability and Reliability
Comply with Telcordia GR-326-CORE specification and RoHS standard
Applications
Date centers
Local Area Networks
High Density Applications
Interconnects
Cross-connects
Technical Specification
Connector | LC Uniboot | Diameter | 2.4mm |
Type Fiber | SM/MM | Outer sheath color | Yellow,Aqua,customized |
Model | PC/APC | Outer sheath material | PVC/LSZH |
Grinding | Duplex | Jump line Puling force | 100N |
Insertion Loss | ≤0.2dB | Return Loss | ≥50dB |
Durability | 1000 | Working temperature | -40℃ ~ +80℃ |
Ordering Information
Type | EndFace | Connector Type | Fiber Mode |
Uniboot | UPC/PC/APC | LC | SM/MM/OM3/OM4 |
